22 Gallon Combustible Chemical Safety Storage Cabinet

Directly supplied by high-quality suppliers, we ensure product quality and after-sales service. As a safety cabinet manufacturing factory, the design of our 22 gallon combustible chemical safety storage cabinets complies with multiple industry standards, guaranteeing the safety of the storage environment.

Product Details

Entirely constructed with double - layer fire - resistant steel plates. There is an insulating layer of 38mm between the two layers of steel plates, which can effectively isolate heat sources.

High - quality cold - rolled steel plates with a thickness of ≥1.0mm are spot - welded, ensuring a longer service life and better fire - resistance.

Three - point linkage door lock can ensure complete closure even without turning the handle, providing maximum fire safety.

Piano - type hinges enable smooth closing and easy opening and closing at 180 degrees.

The cabinet door is equipped with two keys. Additionally, a padlock can be optionally equipped to achieve double - key and double - person safety management.

A 50mm - high anti - leakage liquid trough prevents accidentally spilled liquid from overflowing.

Professionally regulated warning labels are clearly visible.

Double ventilation holes equipped with anti - flashback devices are purposefully placed at the bottom and the top opposite to it.

The unique anti - spill shelf can be freely adjusted up and down and can bear a weight of 120kg.

Both the interior and exterior of the cabinet are coated with epoxy resin electrostatic spray, maintaining a high degree of smoothness and minimizing the impact of corrosion and moisture to the greatest extent.

In strict accordance with OSHA specifications, the cabinet body is equipped with an electrostatic grounding conduction port for easy connection to the electrostatic grounding wire.


Parameter (Specification)

Product Model

Product Parameters

GS022R

Product Name: Combustible Chemical Safety Storage Cabinet

Product Model: GS022R

External Dimensions: H1650×W600×D460mm

Internal Dimensions: H1550×W520×D360mm

Shelf Dimensions: W530×D370×H25mm

Volume: 22/83 (gallons / liters)

Weight: 65kg

Door Opening Method: Manual/Auto

Shelf: Three adjustable shelves

Door Type: Single - door

Lock: Double - lock

Color: Red (Epoxy resin sprayed)


Feature And Application

The eye - catching red exterior conforms to the international standard color for flammable items storage, enabling staff to identify it at a glance. In logistics transfer warehouses where different types of goods are mixed, this red flammable items storage cabinet can be easily distinguished, facilitating the quick location and management of flammable goods and preventing misoperations.

The electrostatic grounding device can promptly conduct the generated static electricity into the ground, effectively avoiding combustion and explosion accidents of flammable items caused by static electricity accumulation. In electronic manufacturing workshops, where there are a large number of equipment and operations prone to generating static electricity, the electrostatic grounding function of the flammable items storage cabinet is particularly crucial, ensuring the safety of flammable chemicals used and stored in the workshop.


Details
